QuadSport Z50 (LT-Z50)
Big Fun For Little Guys
Getting outside and exploring together is one of the joys of being a parent.
Sharing adventure, making discoveries and having fun. That's exactly what the Suzuki QuadSport Z50 is all about.
Like Suzuki's full-size, high-performance quads, it's packed with quality, and style.
The difference is, the QuadSport Z50 is sized to fit the younger fun-seeker.
Features
-
Sharp front mask
-
Throttle limiter
-
Single A-arm front suspension
-
Full floorboards and engine cover
*Click the icons
Specifications
- Engine Type
- 4-stroke, 1-cylinder, air-cooled
- Engine Displacement
- 49 cm3 (3.0 cu. in)
- Bore x Stroke
- 36.0 mm x 48.6 mm (1.4 in x 1.9 in)
- Transmission
- CVT
- Overall Length
- 1,270 mm (50.0 in)
- Overall Width
- 760 mm (29.9 in)
- Overall Height
- 765 mm (30.1 in)
- Wheelbase
- 830 mm (32.7 in)
- Ground Clearance
- 120 mm (4.7 in)
- Seat Height
- 535 mm (21.1 in)
- Curb Mass
- 79 kg (174 lbs)
- Suspension Front
-
Independent, swing axle, coil spring,
oil damped
- Rear
- Swingarm type, coil spring, oil damped
- Brakes Front
- Drum
- Rear
- Drum
- Tires Front
- AT16x8-7☆ , tubeless
- Rear
- AT16x8-7☆ , tubeless
- Fuel Tank Capacity
- 2.6 L (0.7/0.6 US/Imp gal)
